OTS-16-03 IC Programmer adapter Socket

Electra Store SKU: MP-26656

180.00 EGP

In Stock

Quantity

Share to

Overview

The OTS-16-03 is a 16-pin DIP/ZIF (Zero Insertion Force) adapter socket designed for easy programming and testing of 16-pin DIP ICs, such as EEPROMs, microcontrollers, and logic chips. Ideal for electronics repair, development, and prototyping without damaging delicate IC legs.

Description

Key Features:

✔ 16-Pin DIP/ZIF Socket – Zero Insertion Force mechanism for safe IC insertion/removal. ✔ Wide Compatibility – Fits standard 0.3" (7.62mm) DIP-16 ICs (e.g., 24Cxx EEPROMs, 74-series logic, PIC MCUs). ✔ Gold-Plated Contacts – Ensures low resistance and reliable connections. ✔ Durable Construction – Reinforced plastic housing with smooth lever action. ✔ Breadboard-Friendly – 0.1" (2.54mm) pin spacing for easy prototyping. ✔ Works with Programmers – Compatible with TL866, CH341, and universal IC programmers.

Applications:

EEPROM/Flash Programming – Read/write 24C16, 93C46, etc.
Microcontroller Debugging – Test PIC, AVR, or 8051 chips.
Logic IC Testing – Verify 74HC595, CD4017, etc.
Repair & Reverse Engineering – Extract firmware from legacy chips.

Technical Specifications:

Pin Count: 16 (DIP-16, 7.62mm row spacing).
Contact Material: Beryllium copper (gold-plated).
Max Current: 1A per pin (signal/power).
Lifespan: 10,000+ insertions.
Dimensions: ~25mm × 10mm × 8mm.

Package Includes:

1x OTS-16-03 ZIF Socket (16-pin DIP).
Optional: 16-pin ribbon cable (select if needed).

Why Choose This Socket?

✅ Protects IC Pins – No bending or breaking during insertion. ✅ Fast Chip Swapping – Lever-action design saves time. ✅ Versatile – Works with breadboards, programmers, and test fixtures.
