74109 DIP Dual J-NOT-K Positive-Edge-Triggered Flip-Flop With Clear AND Preset

74109 DIP Dual J-NOT-K Positive-Edge-Triggered Flip-Flop With Clear AND Preset

The 74109 DIP flip-flop is a high-performance logic IC. It features dual J-NOT-K inputs. This IC is positive-edge-triggered. It also includes clear and preset functions. Perfect for digital electronics enthusiasts. It works great in counters and registers.

This flip-flop offers reliable operation. It uses standard TTL logic levels. The clear and preset pins give you full control. You can set or reset the output instantly. This makes it ideal for sequential circuits. Build stable and predictable logic systems.

The 74109 DIP flip-flop is a versatile building block. It stores one bit of data per flip-flop. The dual design gives you two independent units. Each unit has its own J and K inputs. The positive-edge-triggering captures data on the clock rise. This prevents glitches and timing errors. The clear and preset pins override the clock. You can force the output high or low. This is useful for initialization. The IC operates from a standard 5V supply. It is compatible with other 74 series chips. The DIP package fits easily into breadboards. You can prototype circuits quickly. The 74109 DIP flip-flop is a trusted choice. It delivers consistent performance in many designs.

Key Features

• Dual J-NOT-K positive-edge-triggered flip-flop in a DIP package
• Includes asynchronous clear and preset for flexible control
• Standard 74 series TTL logic compatible with 5V systems
• Wide operating temperature range for industrial use
• Low power consumption and high noise immunity
• Easy to breadboard and integrate into projects

Use Cases

Use the 74109 DIP flip-flop in digital counters. It works well in shift registers and state machines. Hobbyists and engineers love it for prototyping. It is also great for educational labs. Build timing circuits and memory elements with ease. Typical buyers include students learning logic design. They also include makers building retro computers. Professionals use it in control systems. The 74109 DIP flip-flop fits many projects. It is a core part of sequential logic. You can create dividers, latches, and more. This IC is a staple in any electronics kit.

Order your 74109 DIP flip-flop today. Get fast shipping from Electra Store. Upgrade your electronics projects now. This IC delivers reliable performance every time. The 74109 DIP flip-flop is in stock now. Do not wait to start your next build. Click to add the 74109 DIP flip-flop to your cart. Enjoy great quality and support. Your circuits deserve the best parts. Order now and see the difference.
